Industrial machineryRotary screen drum separator
Rotary trommel screen with barrel floats, support wheels and chain drive — full weldment design with exploded views and fabrication drawing package (AP010).
PortfolioTen years of work,
Ten years of work,
built and shipped.
A selection from 100+ delivered projects across industrial machinery, product design, fixtures and sheet metal. Every project below went from CAD to a real, physical outcome.
Industrial machinery
Material handlingHeavy-duty rolling rack cart
Mobile material-handling cart with twin pin racks and casters — welded frame design delivered as a complete shop drawing set (AP011).
Product designRack-and-pinion clamp mechanism
Compact adjustable clamping device — rack-and-pinion drive, spring return and heat-set inserts, documented with a full exploded view and 21-item BOM (AP009).
Sheet metalFolding door & panel assembly
Four-panel folding door system with custom two-part hinges — assembly drawings, hinge details and a 14-sheet fabrication package.
Industrial machineryIndustrial conveyor system
Modular belt-and-roller conveyor line with 90° curve — full SolidWorks assembly, exploded view with 29-item BOM, 2D drawings and photorealistic renders.
3D renderingAdjustable gym bench
Adjustable FID gym bench modeled in SolidWorks and rendered photorealistically — multi-position mechanism shown in incline, decline and folded states.
